High-Power Integrated LED Chip 10W 20W 30W 50W 100W COB 90-110lm/W Warm Cool White

This high-power integrated LED chip is a component for DIY LED light builds, fixture repair, and custom LED driver projects. The COB-style chip delivers 90–110 lm/W across five power configurations from 10W to 100W, available in warm white and cool white color temperatures. Suitable for high bay lights, flood lights, street lights, and other high-power LED fixture applications.

Critical installation requirement: This chip must be mounted on an aluminum heatsink before operation. Operating the chip without adequate heatsink cooling will cause immediate thermal damage. Do not power on without a heatsink installed.

Two driver voltage ranges are required depending on wattage:

• 10W: 9–12V DC (3S3P configuration)
• 20W, 30W, 50W, 100W: 30–36V DC

A compatible constant-current LED driver matched to the chip's forward current and voltage requirements must be sourced separately.

Certified to CE, RoHS, and EMC standards.

Key Features

• High-power COB integrated LED chip — 90-110 lm/W
• Available in 10W, 20W, 30W, 50W, and 100W
• Warm white (2800-3500K) and cool white (6000-6500K)
• Aluminum heatsink required — not included
• Separate constant-current LED driver required
• CE, RoHS, and EMC certified

Specifications

• Product Type: High-Power Integrated LED Chip (Component)
• Luminous Efficiency: 90-110 lm/W
• Color Temperature: Warm White (2800-3500K) / Cool White (6000-6500K)
• Certification: CE, RoHS, EMC

Applications

• High bay LED fixture chip replacement
• Flood light and street light LED component
• DIY high-power LED build projects
• Custom commercial LED fixture construction
