Ultra-Thin DC 12V 24V LED Recessed Spotlight 3W IP65 Waterproof 304 Stainless Steel 55mm

This ultra-thin DC 12V/24V LED recessed spotlight is built for compact, moisture-resistant installations in bathrooms, kitchen cabinets, display cases, wine cabinets, RV ceilings, and other shallow-ceiling environments where standard recessed fixtures cannot be used. The D72 x H14mm stainless steel body drops into a 55mm ceiling or panel cutout, providing a near-flush finish with minimal ceiling protrusion.

Constructed from 304 stainless steel, the fixture offers strong corrosion and rust resistance suited to humid environments including bathrooms, saunas, and kitchen areas. The IP65 waterproof rating provides protection against water splashes, steam, and moisture ingress from any direction.

The 3W SMD LED chip delivers 280 lumens with a wide 120-degree beam angle, providing comfortable ambient coverage within small cabinet interiors, recessed ceiling panels, and compact room lighting positions. A 17cm pre-attached cable provides wiring length for installation in cabinet panels and ceiling cavities. DC 12V and DC 24V input compatibility suits a range of low-voltage systems including landscape lighting, marine installations, and solar-powered setups.

A separate DC 12V or 24V power supply is required and is not included.

Certified to CE and RoHS standards.

Brand: KPSUN

Model: KPS-02

Key Features

• Ultra-thin 14mm depth for shallow cavity and cabinet installation
• 304 stainless steel body for corrosion and rust resistance
• IP65 waterproof — suitable for bathrooms, kitchens, and wet areas
• 3W LED, 280 lm output
• Wide 120-degree beam angle for even ambient coverage
• D72mm fixture, 55mm cutout
• DC 12V and DC 24V compatible
• 17cm pre-attached cable
• Operating temperature: -30°C to +50°C
• CE and RoHS certified
• 2-year warranty
• Power supply not included

Specifications

• Product Type: Ultra-Thin Recessed LED Spotlight
• Installation Type: Recessed (Embedded)
• Material: 304 Stainless Steel
• Power: 3W
• Input Voltage: DC 12V / DC 24V
• Luminous Flux: 280 lm
• Beam Angle: 120 degrees
• IP Rating: IP65
• Fixture Diameter: D72mm
• Fixture Height: H14mm
• Cutout Size: 55mm
• Cable Length: 17cm
• Operating Temperature: -30°C to +50°C
• Power Tolerance: 3%
• LED Lifespan: Not specified
• Certification: CE, RoHS
• Warranty: 2 Years
• Power Supply: Not included

Applications

• Bathroom ceiling lighting
• Kitchen cabinet and counter lighting
• Display cabinet and wine cabinet lighting
• RV, caravan, and vehicle interior lighting
• Sauna room ceiling lighting
• Marine and boat cabin lighting
• Showcase and retail display lighting
