Ultra-Thin DC 12V 3W LED Recessed Spotlight IP65 Waterproof Cabinet Bathroom 55mm

This ultra-thin DC 12V LED recessed spotlight is engineered for compact, moisture-resistant installations in bathrooms, RV and campervan ceilings, cabinet interiors, display cases, and showcase lighting. At just 14mm deep with a D72mm fixture body and D55mm cutout, the fixture fits into shallow ceiling cavities and cabinet panels where standard-depth downlights cannot be used.

The SMD2835 LED chip delivers 240–300 lumens of output from a 3W draw, with a CRI of over Ra80 and a wide 120-degree beam angle for even, comfortable ambient coverage in confined spaces. Three color temperature options — warm white, natural white, and cool white — allow selection to match the intended application and interior atmosphere.

With an IP65 waterproof rating, the stainless steel nickel-finish body is protected against water splashes and moisture ingress, making it suitable for bathroom ceiling and wet area installation as well as outdoor cabinet and eaves applications. Dimmable functionality supports compatibility with a DC 12V PWM dimmer for brightness adjustment.

DC 12V input requires a separate power supply or transformer which is not included. Rated lifespan of 50,000 hours.

Certified to CE and RoHS standards.

Model: MINI32A-3W

Key Features

• Ultra-thin 14mm depth for shallow cavity and cabinet installation
• IP65 waterproof — suitable for bathrooms and wet areas
• SMD2835 LED chip, 240-300 lm output
• CRI >Ra80 for natural color rendering
• Wide 120-degree beam angle for even coverage
• Stainless steel body with nickel finish
• D72mm fixture, D55mm cutout
• Three color temperatures: Warm White, Natural White, Cool White
• Dimmable — compatible with DC 12V PWM dimmer
• DC 12V input — power supply not included
• LED lifespan: 50,000 hours
• CE and RoHS certified
• 5-year warranty

Specifications

• Product Type: Ultra-Thin Recessed LED Spotlight
• Installation Type: Recessed (Embedded)
• LED Chip: SMD2835
• Power: 3W
• Body Material: Stainless Steel
• Finish: Nickel
• Input Voltage: DC 12V
• Luminous Flux: 240-300 lm
• CRI: >Ra80
• Beam Angle: 120 degrees
• Color Temperature: Warm White (2700-3000K) / Natural White (4000-4500K) / Cool White (6000-6500K)
• IP Rating: IP65
• Fixture Diameter: D72mm
• Cutout Size: D55mm
• Profile Depth: 14mm
• Dimmable: Yes (PWM compatible)
• Power Tolerance: 5%
• LED Lifespan: 50,000 hours
• Certification: CE, RoHS
• Warranty: 5 Years
• Power Supply: Not included

Applications

• Bathroom ceiling lighting
• RV, campervan, and camping car interior lighting
• Cabinet and display case spotlighting
• Showcase and retail display lighting
• Marine and boat cabin lighting
• Window recess and architectural accent lighting
• Outdoor eaves and covered area lighting
